ATW-012T

Wall mounted automatic tap with under-mount sensor eye

Features:
Wall-mounted sensor tap
240mm Length
Under-mount sensor eye
Conserve water and Hygienic
Power: 4XAAA Alkaline batteries (up-to 2yr lifespan)
Hands free infrared activation
Stylish tube design
Solid brass construction
Finish: Chrome-plated

Technical Details:
Water pressure range: 0.75 (Min) - 7 Bar (Max)
Voltage: DC (Batteries Only)
Power consumption: =0.3mW
Sensing distance: 6-24cm
Respond time: 1 Second
Battery Consumption (DC): 4xAAA alkaline batteries (up-to 2yr lifespan depending on level of usage)
Silent Consumption: 0.003mW
Environment Temperature: 1-45 C
Flow Rate: 6L/Per minute
Pipe Threading: British Standard Whitworth (BSW)
Noise Class: 1
Finish: Chrome-plated
Voltage: DC Only

Contents:
1x Sensor Tap (with flexible hose attached)
1x AC cable (UK plug)
1x Transformer

Water pressure:
Water pressure range: 0.7 (Min) - 8 Bar (Max) (1 bar or above for best performance)

Reflective surfaces:
Reflective surfaces issue, see image below

Power Options
DC = Direct Current (Battery source)

DC only: The tap can run off batteries only (4 x AAA batteries)
We recommend using alkaline batteries, which should be new and of the same brand.

Water Supply Feed:
This sensor tap only has a single water supply feed and it's designed to be supplied with pre-mixed water. Consideration should be given to safe hot water delivery and the use of an appropriate temperature reduction device i.e. thermostatic mixer valve.

Drilling a hole?
Standard 30mm hole will suffice.

LIMITED WARRANTY
Autotaps Limited warrants its products (Electronic Sensor Taps) to be made of first class materials, free from defects of material or workmanship under normal use and to perform the service for which they are intended in a thoroughly reliable and efficient manner when properly installed and serviced, for a period of one year (1 year) from date of purchase.

During this period, Autotaps Limited will, at its option, repair or replace any part or parts which prove to be thus defective if returned to Autotaps Limited, at customer’s cost, and this shall be the sole remedy available under this warranty. No claims will be allowed for labour, transportation or other incidental costs. This warranty extends only to persons or organizations who purchased Autotaps products directly from Autotaps Limited. This warranty does not cover the life of the batteries.
